Features :

• Analysis of 3P4W, 3P3W, 1P2W, 1P3W Systems
• Display of 35 Parameters in one screen (3P4W)
• Programmable CT (1 to 600) and PT (1 to 3000) Ratios
• RMS, PEAK Value & Crest Factor
• True RMS value, Active Power, Apparent & Reactive Power ( KVA, KVAR)
• Power Factor, Phase Angle ( ? ) & Energy (WH, KWH, KVARH, PFH)
• Average / Maximum Demand (KW, MW, KVA, MVA) with Progrmmable Period
• Display of 50 Harmonics in one Screen with Wave form with Peak value (1024 Sample / Period)
• Analysis of total Harmonics Destortion (THD-F)
• Capture 28 Transient Events with Programmable Threshold (%) (DIP, SWELL & OUTAGE)
• Built in timer & Calender for Data Logging
• 512K Memory with Programmable interval (2 to 3000 seconds, 17000 records for 3P4W Systems)
• Optical Isolated RS-232C ~ USB Interface
• Calculated Unbalanced Current through Neutral line
• Graphic Phasor Diagram
• Facility to retrieve Power Data & Harmonics on Meter Screen
• Software for easy download of Recorded Data & Transient events
• Graphic Phasor Diagram
• Facility to retrieve Power Data & Harmonics on Meter Screen
• Software for easy download of Recorded Data & Transient events
